北京麦迪森是英国阿佩佐Apiezon中国区代理商，提供Apiezon全系列产品，可提供报关单，TDS，MSDS，COA检测报告等资料，如需选型请联系15301310116（微信同号）

液氦温度下使用铟箔或Apiezon N真空脂时金属压力接触的热导测试

Thermal conductance of pressed metallic contacts augmented with indium foil or Apiezon grease at liquid helium temperatures

Summary:

The thermal conductance of pressed contacts which have been augmented with indium foil or Apiezon N grease has been measured over the temperature range 1.6-6.0 K, with applied forces from 22 to 670N. The sample pairs were fabricated from OFHC copper, 6061-T6 aluminum, free-machining brass and 304 stainless steel. Although the thermal conductance was found to increase with increasing applied contact force, the force dependence was less than in earlier work. The addition of indium foil or Apiezon N grease between the contact surfaces resulted in an improvement over uncoated surfaces ranging from approximately a factor of 3 for stainless steel to an order of magnitude for copper contacts.

 阿皮松Apiezon真空润滑脂选型指南

 【阿皮松Apiezon N应用】液氦温度下使用铟箔或Apiezon N真空脂时金属压力接触的热导测试.pdf

以上是北京麦迪森科技有限公司为您提供的【阿皮松Apiezon N应用】液氦温度下使用铟箔或Apiezon N真空脂时金属压力接触的热导测试，Apiezon产品型号齐全，价格优惠，欢迎您询价15301310116
